Toro 1800 Power Curve Set-Up/Assembly

1800 POWER CURVE
5Service Instruction TSN0001a
13. Insert the RH bolt through the holes and force the
punch out (Fig. 016 and Fig. 017).
14. Install and tighten the nut securing the RH side (Fig.
018).
Fig. 016 PICT-1465
Fig. 017 PICT-1466
Fig. 018 PICT-1468a

Toro 1800 Power Curve Specifications

General

Type	Electric Snow Blower
Power Source	Corded Electric
Clearing Width	18 inches
Intake Height	12 inches
Throw Distance	25 feet
Weight	25 lbs (11.3 kg)
