2.InstallingtheStarterRope
Procedure
Pullthestarterropethroughtheropeguideonthe
handle(Figure5).
Figure5
1.Starterrope
2.Ropeguide
Note:Tomaketheropeeasiertoinstall,squeezethe
controlbaronthehandle.
3.FillingtheEnginewithOil
Procedure
Yourmowerdoesnotcomewithoilintheengine.
1.Removethedipstick(Figure6).
Figure6
2.Slowlypouroilintotheoillltubeuntiltheoillevel
reachestheFulllineonthedipstick(Figure6).Do
notoverll.(Max.ll:20oz.(0.59l),type:SAE
30WdetergentoilwithanAPIserviceclassication
ofSF,SG,SH,SJ,SL,orhigher.)
3.Installthedipsticksecurely.
Important:
Change the engine oil after the r st
5 operating hour s ;changeityearlythereafter.
RefertoChangingtheEngineOil.
ProductOverview
Figure7
Self-propelmodelshown
1.Cuttingheightlever(4)
6.Recoilstarthandle
2.Sparkplug
7.Bladecontrolbar
3.Airlter8.Upperhandle(self-propel
modelonly)
4.Fueltankcap9.Washoutport
5.Oilll/Dipstick
Figure8
1.Sidedischargechute
2.Reardischargeplug
(installed)
