ServiceProcedureIcons

ThefollowingiconsappearthroughoutthisServiceManualtobringattentionto

specicimportantdetailsofaserviceprocedure.

CriticalProcess

Thisiconisusedtohighlight:

•Installingsafetyequipment(shields,guards,seatbelts,brakes,andR.O.P .S.

components)thatmayhavebeenremoved

•Dimensionsorsettingsthatmustbemaintainedforpropermachineoperation

•Aspecicfastenertighteningsequence

•Componentorientationthatmaynotbeobvious

CriticalTorque

Thisiconisusedtohighlightanassemblytorquerequirementthatisdifferent

thanwhatisrecommendedintheStandardTorqueT ables.

FluidSpecications

Thisiconisusedtohighlightuidspecicationsandcapacitiesthatareless

common,andmaynotappearonthemachineservicedecalorinthemachine

Operator’sManual.

Note:RefertotheservicedecalonthemachineandthemachineOperator’s

Manualforcommonlyuseduidspecicationsandcapacities.

Preface

Page4

60vWPMServiceManual

3429-828RevA
