Toro 20381 User Manual

Setup
Important:Removeanddiscardtheprotectiveplastic
sheetthatcoverstheengineandanyotherplasticor
wrappingonthemachine.
Important:Topreventaccidentalstarting,donotinsert
theelectric-startbuttonintotheelectricstarterswitch
untilyouarereadytostarttheengine.
1
AssemblingandUnfoldingthe
Handle
Partsneededforthisprocedure:
2Handlebolt
2Washer
Procedure
WARNING
Assemblingandunfoldingthehandleimproperly
candamagethecables,causinganunsafeoperating
condition.
•Donotdamagethecableswhenassemblingand
unfoldingthehandle.
•Ensurethatthecablesareroutedtotheoutside
ofthehandle.
•Ifacableisdamaged,contactanAuthorized
ServiceDealer.
1.Raisetherearofthemachinehousingtoits
highestcutting-heightsettingbymovingthe2rear
cutting-heightleversallthewayforward.Referto
AdjustingtheCuttingHeight(page10).
2.Attachthehandleendstothemachinehousingwith
2washersand2handlebolts(Figure4),butdonot
tightenthehandlebolts.
G017457
g017457
Figure4
1.Washer3.Handleend
2.Handlebolt
Important:Routethecablestothe outside ofthe
handle(Figure4).
3.Rotatethehandlerearward(Figure5).
g189343
Figure5
4.Lockthehandleatyourdesiredheight.Referto
AdjustingtheHandleHeight(page9).
5.Torquethehandleboltsto14to17N∙m(120to160
in-lb).
6.Adjustthecuttingheight.RefertoAdjustingthe
CuttingHeight(page10).
5

Toro 20381 Specifications

General

Brand	Toro
Model	20381
Category	Lawn Mower
Power Source	Gasoline
Engine	Briggs & Stratton
Engine Displacement	163cc
Cutting Width	21 inches
Deck Material	Steel
Mulching Capability	Yes
Bagging Capability	Yes
Side Discharge	Yes
Fuel Type	Unleaded Gasoline
Start Type	Recoil
Type	Walk-Behind
Fuel Capacity	0.25 gallons
Wheel Size	8 inches
Cutting Height	1.0 - 4.0 in (2.5 - 10 cm)
