Page #6 background imageLoading...
Page #6 background image
2
InstallingtheRecoil-starter
RopeintheRopeGuide
NoPartsRequired
Procedure
Important:Tostarttheenginesafelyandeasily
wheneveryouusethemachine,installtherecoil-starter
ropeintheropeguide.
Holdtheblade-controlbartotheupperhandleandpullthe
recoil-starterropethroughtheropeguideonthehandle
(Figure6).
g003251
Figure6
1.Recoil-starterrope2.Ropeguide
3
FillingtheEnginewithOil
NoPartsRequired
Procedure
Important:Yourmachinedoesnotcomewithoilin
theengine.Beforestartingtheengine,lltheengine
withoil.
Engineoilcapacity:0.5L(18.oz)
Oilviscosity:SAE30orSAE10W-30detergentoil
APIserviceclassication:SJorhigher
1.Movethemachinetoalevelsurface.
2.Waitfor3to5minutesfortheoiltosettle.
3.Removethedipstick(Figure7)andpourabout3/4
ofthecrankcasecapacityofthespeciedoilintothe
oil-lltube.
g186624
Figure7
1.Full3.Low
2.High
4.Wipeoffthedipstickendwithacleancloth.
5.Insertthedipstickintotheoil-lltube,butdonot
screwitin,thenremovethedipstick.
6.Readtheoillevelonthedipstick(Figure7).
IftheoilisbelowtheAddmarkonthedipstick,
slowlypourasmallamountofoilintotheoil-ll
tube,wait3minutes,andthenrepeatsteps3
through5untiltheoillevelisattheFullmarkon
thedipstick
IftheoilisabovetheFullmarkonthedipstick,
draintheexcessoiluntiltheoillevelisattheFull
markonthedipstick.Todraintheexcessoil,refer
toChangingtheEngineOil(page19).
Important:Iftheoillevelinthecrankcaseis
toolowortoohighandyouruntheengine,
youmaydamagetheengine.
7.Installthedipstickintotheoil-lltubesecurely.
Important:Checktheengine-oillevelbeforeeach
useandaddoilasneeded;refertoCheckingthe
Engine-OilLevel(page9).
4
ChargingtheBattery
NoPartsRequired
Procedure
Electric-StartModelOnly
RefertoChargingtheBattery(page20).
6

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Toro 20381 and is the answer not in the manual?

Toro 20381 Specifications

General IconGeneral
BrandToro
Model20381
CategoryLawn Mower
Power SourceGasoline
EngineBriggs & Stratton
Engine Displacement163cc
Cutting Width21 inches
Deck MaterialSteel
Mulching CapabilityYes
Bagging CapabilityYes
Side DischargeYes
Fuel TypeUnleaded Gasoline
Start TypeRecoil
TypeWalk-Behind
Fuel Capacity0.25 gallons
Wheel Size8 inches
Cutting Height1.0 - 4.0 in (2.5 - 10 cm)
