ProductOverview
g189025
Figure10
1.Cutting-heightlever(4)
8.Blade-controlbar
2.Sparkplug
9.Upperhandle
3.Oilll/Dipstick(notshown)
10.Electric-startbutton
(electric-startmodelonly)
4.Fueltankcap
11.Battery(electric-start
modelonly)
5.Reardoor12.Washoutport
6.Recoilstarthandle
13.Airlter
7.Adjustmentknobforthe
self-propeldrive
g007283
Figure11
1.Grassbag
3.Batterycharger
(electric-startmodelonly)
2.Side-dischargechute4.Rearplug(installed)
Operation
BeforeOperation
BeforeOperationSafety
GeneralSafety
Becomefamiliarwiththesafeoperationoftheequipment,
operatorcontrols,andsafetysigns.
Checkthatallguardsandsafetydevices,suchasdeectors
and/orgrasscatcher,areinplaceandworkingproperly.
Alwaysinspectthemachinetoensurethattheblades,
bladebolts,andcuttingassemblyarenotwornor
damaged.
Inspecttheareawhereyouwillusethemachineand
removeallobjectsthatthemachinecouldthrow.
Adjustingthecuttingheightmaybringyouintocontact
withthemovingblade,causingseriousinjury.
Shutofftheengine,removetheelectric-startbutton
(electric-startmodelonly),andwaitforallmoving
partstostop.
Donotputyourngersunderthehousingwhen
adjustingthecuttingheight.
FuelSafety
DANGER
Fuelisextremelyammableandhighlyexplosive.
Areorexplosionfromfuelcanburnyouand
othersandcandamageproperty.
Topreventastaticchargefromignitingthefuel,
placethecontainerand/ormachinedirectlyon
thegroundbeforelling,notinavehicleoron
anobject.
Fillthefueltankoutdoors,inanopenarea,when
theengineiscold.Wipeupanyfuelthatspills.
Donothandlefuelwhensmokingoraroundan
openameorsparks.
Storefuelinanapprovedcontainerandkeepit
outofthereachofchildren.
WARNING
Fuelisharmfulorfatalifswallowed.Long-term
exposuretovaporscancauseseriousinjuryand
illness.
Avoidprolongedbreathingofvapors.
Keepyourhandsandfaceawayfromthenozzle
andthefuel-tankopening.
Keepfuelawayfromyoureyesandskin.
8
