Toro 21750 - Adjusting the Self-Propel Drive

g231390
Figure26
Important:Positionthecurvedendsofthe
bladetopointtowardthemachinehousing.
6.Useatorquewrenchtotightenthebladebolt
to82N∙m(60ft-lb).
AdjustingtheSelf-Propel
Drive
Wheneveryouinstallanewself-propelcableorif
theself-propeldriveisoutofadjustment,adjustthe
self-propeldrivecable.
1.Loosenthecable-supportnut(Figure27).
g009692
Figure27
1.25to38mm(1to1-1/2
inches)
4.Cable-supportnut
2.Self-propel-drivebar5.Cablesupport
3.Cablejacket
2.Holdtheself-propel-drivebar25to38mm(1to
1-1/2inches)fromthehandle(Figure27).
3.Pulldownthecablejacket(towardthemachine)
untilthereisnoslackinthecable(Figure27).
4.Tightenthenutonthecablesupport.
5.Releasetheself-propel-drivebarandensure
thatthecableisloose.
Note:Thecablemustbeloosewiththe
self-propeldrivebarinthereleasedposition;
otherwise,themachinemaycreepwhenyou
disengagethebar.
