Toro 21750 - Setup; Installing the Handle; Installing the Recoil-Starter Rope in the Rope Guide

Setup
Important:Removeanddiscardtheprotectiveplasticsheetthatcoverstheengineandanyother
plasticorwrappingonthemachine.
Important:Topreventaccidentalstarting,donotinsertthekeyintotheelectric-startignition(if
equipped)untilyouarereadytostarttheengine.
1
InstallingtheHandle
NoPartsRequired
Procedure
WARNING
Foldingorunfoldingthehandleimproperlycandamagethecables,causinganunsafe
operatingcondition.
•Donotdamagethecableswhenfoldingorunfoldingthehandle.
•Ifacableisdamaged,contactanAuthorizedServiceDealer.
1.Removethehandleknobsandcorrespondingboltsfromthelowerhandles(AofFigure3).
2.Positiontheupperhandleonthelowerhandlesandthenunfoldthehandle(BofFigure3).
3.Ensurethatthecablesareroutedtotheoutsideofthehandle(CofFigure3).
4.Installthehandleknobswiththecorrespondingboltsandtightenthemrmlybyhand(DofFigure3).
g305902
Figure3
2
InstallingtheRecoil-StarterRopeintheRopeGuide
NoPartsRequired
Procedure
Important:Tostarttheenginesafelyandeasilywheneveryouusethemachine,installtherecoil-starter
ropeintheropeguide.
