Lubrication
LubricatingthePivotArms
ServiceInterval:Every25hours
1.Movetherearwheelcuttingheightleverstothe
centersetting.
2.Wipethegreasettingswithacleanrag(
Figure22).
Figure22
1.Greasetting
3.Installagreasegunontothettingandgentlyapply2
or3pumpsof#2multi-purposelithium-basegrease.
Important:Excessivegreasepressuremay
damagetheseals.
LubricatingtheGearCase
ServiceInterval:Every100hours
1.Removethegrassbag.
2.Installagreasegunontothettingthroughthebelt
coveropening(
Figure23).
Figure23
1.Beltcover
2.Greasetting
3.Gentlyapplyoneto2pumpsof#2multi-purpose
lithium-basegrease.
4.Installthegrassbag.
EngineMaintenance
ServicingtheAirFilter
ServiceInterval:Every25hours—Cleanthefoam
pre-cleaner(morefrequentlyindusty
conditions).
Every300hours—Replacethepaper
airlter(morefrequentlyindusty
conditions).
Important:Donotoperatetheenginewithoutthe
airlterassembly;extremeenginedamagewill
occur.
1.Stoptheengineandwaitforallmovingpartstostop.
2.Disconnectthewirefromthesparkplug(
Figure11).
3.Removethecoverandcleanitthoroughly(Figure24).
Figure24
1.Cover3.Airlterbase
2.Paperairlter
4.Removeandinspectthepaperairlter(Figure24),
anddiscarditifitisexcessivelydirty.
Important:Donottrytocleanapaperlter.
5.Removethefoampre-cleanerandwashitwithamild
detergentandwater,thenblotitdry(
Figure24).
6.Installthefoampre-cleanerontothepaperairlter.
7.Installtheairlterassembly.
Note:Installanewpaperairlterifyoudiscarded
theoldone.
8.Installthecover.
