Toro 30172TE - Wiring Diagram

28
Wiring Diagram
T1
D4D1D3
D2
K1
GN
BK
BK BK
2
3
5
4
1
R1
R2
C1
GND
PTO CLUTCH
P5–4
P5–3
J9–1
HOURMETER (OPTIONAL)
PK
DELAY MODULE
7.5A
F1
G M
S1 IGNITION
S3 BAIL SW. (NORMALLY OPEN)
S2 CLUTCH SW. (MOMENTARY)
ORPK
W
BK
P5–2 P5–1
BK
PINK RED TAN
BLACK
WIRE COLOR CODES
BROWN BLUE
WHITE VIOLET YELLOW
ORANGE GREY GREEN
BN
W VIOGN
GY OR Y BU BN
PK R T
BK
KEY SW.
G M
KEY SWITCH P/N 29–5560
NONE G+MOFF
ON
W
PK
J8–1
SPARK PLUG
ENGINE
IGNITION MODULE
MAG AC
W
BK
BU
PK BU
BU
+–
BRIDGE RECTIFIER
R4 R3
D5 C2
D6
PK
HOURMETER (OPTIONAL)
