Toro 30192 - Assembly; Loose Parts

12
Assembly
Loose Parts
Note: Use the chart below to verify all parts have been shipped.
DESCRIPTION QTY. USE
Wheel
Nut
2
8
Install drive wheels
Upper handle
Flanged bolt 3/8–16 x 1” (26 mm)
Flange nut 3/8–16
1
4
4
Install upper handle to frame
Clevis pin
Washer
Hairpin cotter
1
1
2
Install control rods
Battery
Battery holder
Battery pad
Bolt 3/8–16 x 1-3/4” (44 mm)
Locknut 3/8–16
Battery strap
Battery support rod
Locknut 1/4–20
Carriage bolt 1/4–20 x 3/4” (19 mm)
Nut 1/4–20
Terminal boot
1
2
2
2
2
1
2
2
2
2
2
Install battery
Flange bolt 1/2–13 x 1-1/4” (32 mm)
Flange bolt 1/2–13 x 1-3/4” (44 mm)
4
2
Replace (6) 1/2–13 x 1” (26 mm) flange bolts
supplied with mowers
Hydraulic filter 1 Use for initial hydraulic filter change
Operator’s Manual
Engine Operator’s Manual
Parts Catalog
Registration card
1
1
1
1
Read before operating machine
Fill out and return to Toro
