•Steering-platebushings(Figure39)
g001225
Figure39
•Axle-pinbushing(Figure39)
•Driveshaft(3)(Figure40)
Note:4-wheeldrivemodelsonly.
g034257
Figure40
•Tie-rodends(2)(Figure41)
g001251
Figure41
•Cylinder-rodends(2)(Figure41)
•Steeringpivots(2)(Figure41)
•Axle-pivotpin(Figure41)
Note:Improperwash-downproceduresnegatively
affectbearinglife.Donotwashdownthemachine
whenitisstillhotandavoiddirectinghigh-pressureor
high-volumesprayatthebearings.
