Figure34
1.Seatsuspensionknob2.Operatorweightsetting
ChangingtheBackPosition
Thebackoftheseatcanbeadjustedtoprovidea
comfortableride.Positionthebackoftheseatwhereit
ismostcomfortable.
Toadjustit,turntheknob,undertheright-sidearm
rest,ineitherdirectiontoprovidethebestcomfort
(
Figure33).
ChangingtheLumbarSupport
Thebackoftheseatcanbeadjustedtoprovidea
customizedlumbarsupportforyourlowerback.
Toadjustit,turntheknob,undertheleft-sidearm
rest,ineitherdirectiontoprovidethebestcomfort
(
Figure33).
UnlatchingtheSeat
Toaccessthehydraulicandothersystemsunderthe
seat,youneedtounlatchtheseatandswingitforward.
1.Usetheseatpositionadjustmentlevertoslidethe
seatallthewayforward.
2.Pushoneoftheseatlatches,locatedbehindandto
thesidesoftheseat,rearwardtounlatchtheseat
andpullforwardonthetopoftheseat(
Figure35).
Figure35
1.Seatlatch
PushingtheMachinebyHand
Ifthemachinebreaks,runsoutoffuel,etc.youmay
needtopushit.Todoso,yourstneedtoopenthe
hydraulicby-passvalves.
Important:Alwayspushthemachinebyhand.
Nevertowthemachinebecausehydraulicdamage
mayoccur.
PushingtheMachine
1.Disengagethepowertakeoff(PTO)andturn
theignitionkeytooff.Movetheleverstothe
neutrallockedpositionandapplytheparkingbrake.
Removethekey.
2.Lifttheseat.
3.Rotateeachby-passvalvecounterclockwise1turn
(
Figure36).
Thisallowshydraulicuidtoby-passthepump
enablingthewheelstoturn.
Important:Donotrotatetheby-passvalves
morethan1turn.Thispreventsvalvesfrom
comingoutofthebodyandcausinguidto
runout.
