Toro 30366 - 4 Replacing the Traction Unit PTO Shaft; 5 Connecting the PTO Shaft to the Cutting Unit Gear Box; 6 Greasing the Machine

4
ReplacingtheTractionUnit
PTOShaft(CuttingUnitModel
30366only)
NoPartsRequired
Procedure
CuttingunitModel30366isequippedwithashorter
PTOshaftwhichmustbeinstalledonthetractionunit
asfollows:
1.Removethecotterpin,boltsandlocknutssecuring
thefemaleendofthePTOshafttothetractionunit
shaft.
2.RemovethePTOshaftfromthetractionunitshaft
andretainitforfutureapplications.
3.InstallthefemaleendofthePTOshaft,supplied
withthecuttingunit,tothetractionunitshaftwith
thecotterpin.
4.Tightentheboltsandlocknuts.
5
ConnectingthePTOShaftto
theCuttingUnitGearBox
NoPartsRequired
Procedure
1.SlidethemalePTOshaftintothefemalePTOshaft.
Alignthemountingholesinthegearcaseinput
shaftwiththeholesinthePTOshaftandslidethem
together.
Figure5
1.PTOshaft3.Gearcase
2.Boltsandlocknuts4.Rollpin
2.Securethemwitharollpin.
3.Tightentheboltsandnuts.
6
GreasingtheMachine
NoPartsRequired
Procedure
Beforeoperatingthemachine,itmustbegreased
toensureproperlubricatingcharacteristics;referto
GreasingtheBearingsandBushings.Failuretoproperly
greasethemachinewillresultinprematurefailureof
criticalparts.
11
