5.ConnecttheDiagnosticACEconnectortotheharness
connector.
Note:Makesurecorrectoverlaydecalispositioned
onDiagnosticACE.
6.TurnthekeyswitchtotheONposition,butdonot
startmachine.
Note:Theredtextontheoverlaydecalreferstoinput
switchesandthegreentextreferstooutputs.
7.The“outputsdisplayed”LED,onlowerrightcolumn
ofDiagnosticACE,shouldbeilluminated.Ifthe
“inputsdisplayed”LEDisilluminated,pressthetoggle
button,ontheDiagnosticACE,tochangetheLEDto
“outputsdisplayed”.
Note:Itmaybenecessarytotogglebetween“inputs
displayed”and“outputsdisplayed”severaltimestodo
thefollowingstep.Totogglebackandforth,press
thetogglebuttononce.Thismaybedoneasoftenas
required.Donotholdthebutton.
8.Sitontheseatandattempttooperatethedesired
functionofthemachine.Theappropriateoutput
LEDsshouldilluminatetoindicatethattheECMis
turningonthatfunction.
Note:IfthecorrectoutputLEDsdonotilluminate,verify
thattherequiredinputswitchesareinthenecessarypositions
toallowthatfunctiontooccur.Verifycorrectswitchfunction.
IftheoutputLEDsareonasspecied,butthemachinedoes
notfunctionproperly,thisindicatesanon-electricalproblem.
Repairasnecessary.
Note:Ifeachoutputswitchisinthecorrectpositionand
functioningcorrectly,buttheoutputLEDsarenotcorrectly
illuminated,thisindicatesanECMproblem.Ifthisoccurs,
contactyourToroDistributorforassistance.
Important:TheDiagnosticACEdisplaymustnotbe
leftconnectedtothemachine.Itisnotdesignedto
withstandtheenvironmentofthemachine'severyday
use.WhendoneusingtheDiagnosticACE,disconnect
itfromthemachineandconnectloop-backconnector
toharnessconnector.Themachinewillnotoperate
withoutloopbackconnectorinstalledontheharness.
StoretheDiagnosticACEindry,securelocationinthe
shop,notonthemachine.
PositioningtheStandardSeat
ChangingtheSeatPosition
Theseatcanmoveforwardandbackward.Positiontheseat
whereyouhavethebestcontrolofthemachineandaremost
comfortable.
1.Toadjust,movetheleversidewaystounlocktheseat
(Figure29).
Figure29
1.Backrestknob3.Lumbarsupport
adjustmentknob
2.Seatsuspensionknob4.Seatpositionadjustment
lever
2.Slidetheseattothedesiredpositionandreleaselever
tolockinposition.
3.Verifythattheseathaslockedintoplacebyattempting
tomoveitbackandforth.
ChangingtheSeatSuspension
Theseatcanbeadjustedtoprovideasmoothandcomfortable
ride.Positiontheseatwhereyouaremostcomfortable.
Withoutsittingontheseat,turntheknobinfronteither
directiontoprovidethebestcomfort(Figure29).
Figure30
1.Seatsuspensionknob2.Operatorweightsetting
ChangingtheBackPosition
Thebackoftheseatcanbeadjustedtoprovideacomfortable
ride.Positionthebackoftheseatwhereitismost
comfortable.
Toadjustit,turntheknob,undertheright-sidearmrest,in
eitherdirectiontoprovidethebestcomfort(
Figure29).
