Toro 30534 - Adjusting the Maximum Ground Speed; Adjusting the Mow Speed Limiter Lever

Figure59
1.Transmissioncontrolrods
•Iftheleftreartireisrotatinginreverse,lengthen
therodbyslowlyturningtherodcounter-clockwise
(asviewedfromthefront)untiltheleftreartire
stopsrotatingorminimalrotationisdetectedin
reverse
•Iftheleftreartireisrotatingforward,shortenthe
rodbyslowlyturningtherodclockwise(asviewed
fromthefront)untiltheleftreartirestopsrotating.
4.MovethethrottletotheFastposition.Makesurethe
wheelremainsstoppedorminimalcreepisdetectedin
reverse.Adjustasrequired.
5.Tightenthejamnuts.
6.Repeattheprocedurefortherightreartire,ifrequired,
byusingtherightsidetransmissioncontrolrod.
7.Stoptheengine.Removethejackstandsandlowerthe
machinetotheshopoor.
8.Testdrivethemachinetomakesureitdoesnotcreep.
AdjustingtheMaximum
GroundSpeed
1.DisengagethePTO,releasethetractionpedaltothe
neutralpositionandsettheparkingbrake.
2.MovethethrottlelevertotheSlowposition,stopthe
engine,removethekey,andwaitforallmovingpartsto
stopbeforeleavingtheoperatingposition.
3.Loosenthejamnutonthestopboltforthetraction
pedal(Figure60).
Figure60
1.Tractionpedal
3.1.5mm(0.060inch)
2.Stopboltw/jamnut
(forward)
4.Stopboltw/jamnut
(reverse)
4.Adjustthestopboltallthewayin(awayfromthe
tractionpedal).
5.Usingyourhand,pushthetractionpedalalltheway
forward,withlightpressure,untilitstopsandholdit
there.Maintainonlylightpressureonthepedalwhen
pushingittothefullforwardposition.
6.Withtheseatintheraisedposition,verifythatyou
arenotoverloadingthelinkagebymakingsure
thetransmissiondoesnotmovewhenthepedalis
depressedtothestop.
7.Adjustthestopboltout(towardsthetractionpedal)
untilthereisagapof1.5mm(0.060inch)betweenthe
headofthestopboltandthebottomofthetraction
pedal.
8.Tightenthejamnuttosecurethestopboltinplace.
9.Thereversestopboltmaybeadjustedifthemaximum
reversespeedisnotacceptable.Forafasterreverse
speed,adjustthestopboltin.Foraslowerreverse
speed,adjustthestopboltout.
AdjustingtheMowSpeed
LimiterLever
Themowspeedlimiterlever(Figure61)canbeipped
forwardtolimitthetractionspeedwhileoperating.
1.DisengagethePTO,releasethetractionpedaltothe
neutralpositionandsettheparkingbrake.
2.MovethethrottlelevertotheSlowposition,stopthe
engine,removethekey,andwaitforallmovingpartsto
stopbeforeleavingtheoperatingposition.
3.Loosenthejamnutonthemowspeedlimiterstopbolt
(
Figure61).
