DPFSootAccumulation

•Overtime,theDPFaccumulatessootinthesoot

lter.Thecomputerfortheenginemonitorsthe

sootlevelintheDPF.

•Whenenoughsootaccumulates,thecomputer

informsyouthatitistimetoregeneratethediesel

particulatelter.

•DPFregenerationisaprocessthatheatstheDPF

toconvertthesoottoash.

•Inadditiontothewarningmessages,thecomputer

reducesthepowerproducedbytheengineat

differentsoot-accumulationlevels.

EngineWarningMessages—SootAccumulation

IndicationLevel

FaultCode

EnginePowerRatingRecommendedAction

Level1:Engine

Warning

g213866

Figure33

CheckEngine

SPN3719,FMI16

Thecomputerde-ratesthe

enginepowerto85%

Performaparkedregeneration

assoonaspossible;referto

ParkedRegeneration(page40).

Level2:Engine

Warning

g213867

Figure34

CheckEngine

SPN3719,FMI0

Thecomputerde-ratesthe

enginepowerto50%

Performarecoveryregeneration

assoonaspossible;referto

RecoveryRegeneration

(page43).
