Toro 30686 - Lubricating the Caster and Wheel Bearings; Greasing the Transmission Couplers; Greasing the Mower Belt Idler

2.Stoptheengine,removethekey,andwaitforall
movingpartstostopbeforeleavingtheoperating
position.
3.Cleanthegreasettingswitharag.Makesureto
scrapeanypaintoffthefrontofthetting(s).
4.Connectagreaseguntothetting.Pumpgrease
intothettingsuntilgreasebeginstooozeoutof
thebearings.
5.Wipeupanyexcessgrease.
LubricatingtheCasterand
WheelBearings
ServiceInterval:Beforeeachuseordaily
Every400hours
Every400hours
1.Lubricatethefrontwheelbearingsandfrontspindles
(
Figure19).
2.Lubricatethedrivewheelbearings.
Figure19
GreasingtheTransmission
Couplers
ServiceInterval:Every250hours
Lubricatethetransmissioncouplerslocatedintheback
ofthemachine(Figure20).
Figure20
GreasingtheMowerBeltIdler
ServiceInterval:Every50hours
Greasethettingonthemowerbeltidlerarmpivot
(Figure21).
Note:Removethemowerdeckcovertoaccessthe
greasettingforthemowerbeltidlerarm.
Figure21
26
