2
InstallingtheRecoilStarter
Handle
NoPartsRequired
Procedure
Installtherecoilstarterhandleintheropeguideas
showninFigure4.
Figure4
1.Ropeguide
3
InstallingtheDischargeChute
Assembly
Partsneededforthisprocedure:
1Dischargechuteassembly
2
Screws
2Washers
2Locknuts
1Knob
Procedure
InstallthedischargechuteassemblyasshowninFigure5.
Figure5
1.Knob
2.Bolt(2),washer(2),and
locknut(2)
Note:Installtheboltsfromtheinsideofdischarge
chuteassemblysothatthewashersandlocknutsareon
theoutsideofthechute.
Important:Donotovertightenthelocknuts.
4
FillingtheEnginewithOil
Partsneededforthisprocedure:
1
Bottleofengineoil
Procedure
Yourmachinedoesnotcomewithoilintheengine,but
itdoescomewithabottleofoil.
Important:Beforestartingtheengine,llthe
enginewithoil.
Maxll:12oz.(0.35l),type:automotivedetergentoil
withanAPIserviceclassicationofSJ,SL,orhigher.
Use
Figure6toselectthebestoilviscosityforthe
outdoortemperaturerangeexpected:
6
