InstallingtheUpperHandle

Partsneededforthisprocedure:

2Handlebolts

Curvedwashers

2Locknuts

Procedure

1.Liftandrotatetheupperhandleandpositionitover

thelowerhandle(Figure3).

2.Install2handlebolts,2curvedwashers,and2locknuts

inthelowerhandleholes(Figure3).

g019003

Figure3

InstallingtheTractionControl

Linkage

NoPartsRequired

Procedure

1.Removethehairpincotterandwasherfromthelower

endofthespeedcontrolrodandinsertthelowerend

oftherodintothelowerlinkarmsothatthebentend

ofthespeedcontrolrodfacesrearward(Figure4).

g019004

Figure4

2.Securethelowerendofthespeedcontrolrodwiththe

washerandhairpincotterthatyoupreviouslyremoved.

3.Removethehairpincotterandtheouterwasherfrom

thetrunnionontheupperendofthespeedcontrol

rod(Figure5).

Figure5

1.Speedselectorlever

3.Innerwasher

2.Trunnion

4.Outerwasher

Note:Tomakeinstallationeasier,leavetheatwasher

onthetrunnion(Figure5).

4.ShiftthespeedselectorleverintoPositionF6.
