Toro 38812 - Lubricating the Hex Shaft

Note:Disposeoftheusedoilproperlyatalocal
recyclingcenter.
5.Installtheoil-draincapandtightenitsecurely.
6.Cleanaroundtheoilll/dipstick.
7.Unscrewthedipstickandremoveit.
8.Carefullypourabout3/4oftheenginecapacity
ofoilintotheoil-lltube.
UseFigure32toselectthebestoilviscosityfor
theoutdoortemperaturerangeexpected:
g011606
Figure32
9.Wait3minutesfortheoiltosettleintheengine.
10.Wipethedipstickcleanwithacleancloth.
11.Insertthedipstickintotheoil-lltube,screwitin,
thenremovethedipstick.
12.Readtheoillevelonthedipstick.
•Iftheoillevelonthedipstickistoolow,
carefullypourasmallamountofoilinto
theoil-lltube,wait3minutes,andrepeat
steps10through12untiltheoillevelonthe
dipstickiscorrect.
•Iftheoillevelonthedipstickistoohigh,
draintheexcessoiluntiltheoillevelonthe
dipstickiscorrect.
Important:Iftheoillevelintheengineistoo
lowortoohighandyouruntheengine,you
maydamagetheengine.
13.Installthedipstickintotheoil-lltubesecurely.
LubricatingtheHexShaft
ServiceInterval:Yearly—Lubricatethehexshaft.
Lightlylubricatethehexshaftyearlywithautomotive
engineoil(Figure33).
g019018
Figure33
1.Hexshaft
3.Rubberwheel
2.Steelfrictionpulley
Important:Donotgetoilontherubberwheelor
thesteelfrictionpulleybecausethetractiondrive
willslip(Figure33).
1.Drainthefuelfromthefueltank.
2.Tipthemachineforwardontoitsaugerhousing
andblockitsothatitcannotfall.
3.Removethebackcover(Figure34).
g019019
Figure34
1.Screws
4.Movethespeed-selectorlevertoPositionR2.
5.Dipyourngerinautomotiveengineoiland
lightlylubricatethehexshaft.
6.Movethespeed-selectorlevertoPosition6.
7.Lubricatetheotherendofthehexshaft.
8.Movethespeed-selectorleverforwardand
rearwardafewtimes.
9.Installthebackcoverandreturnthemachineto
theoperatingposition.
23
