Themachineshouldmoverearward.Ifthe
machinedoesnotmoveormovesforward,
completethefollowing:
A.Releasethetractionleverandshutoffthe
engine.
B.Disconnectthetrunnionfromthe
speed-selectorlever.
C.Turnthetrunniondownward(clockwise)on
thespeed-controlrod.
D.Connectthetrunniontothespeed-selector
lever.
4.Releasethetractionlever.
5.MovethespeedselectortoPosition1;referto
OperatingtheSpeedSelector(page13).
6.Squeezetheleft(traction)levertothehandgrip
(Figure9).
Themachineshouldmoveforward.Ifthe
machinedoesnotmoveormovesrearward,
completethefollowing:
A.Releasethetractionleverandshutoffthe
engine.
B.Disconnectthetrunnionfromthe
speed-selectorlever.
C.Turnthetrunnionupward(counterclockwise)
onthespeed-controlrod.
D.Connectthetrunniontothespeed-selector
lever.
7.Ifyoumadeanyadjustments,repeatthis
procedureuntilnoadjustmentsarerequired.
Important:Ifthemachinemoveswhenthe
tractionleverisinthereleasedposition,checkthe
tractioncable;refertoCheckingandAdjusting
theTractionCable(page18)ortakethemachine
toanAuthorizedServiceDealerforservice.
ProductOverview
g322825
Figure10
1.Handgrip(2)10.Scraper
2.Auger/impellerlever
11.Auger
3.Speed-selectorlever12.Skid(2)
4.QuickStick®
discharge-chutecontrol
13.Headlight
5.Tractionlever14.Electric-startbutton
6.Fuel-tankcap15.Electric-startplug-in
7.Oil-lltube/dipstick
16.Recoil-starthandle
8.Chutedeector17.Snow-cleanouttool
9.Dischargechute
g016500
Figure11
1.Primer5.Throttle
2.Key
6.Oil-drainplug
3.Choke
7.Recoil-starthandle
4.Fuel-shutoffvalve
