RibbedV-BeltRemoval(continued)
5.Removetherotorpulleyassemblyfromtherotorshaft.
g320312
Figure17
6.RemoveribbedV-beltfromtherotorpulleyassemblyandthemotorpulley.
RibbedV-BeltInstallation
1.Installtherotorpulleyassemblyontotherotorshaft.InstalltheBelleville
washerandnewscrewsecuringtherotorpulleyassemblytotherotorshaft.
Torquescrewto10–12.4N•m(90-110in-lb).
2.ApplyLoctitetothreadsofmotorpulley.
3.ThreadthenewribbedV-beltaroundthemotorpulleyandroutetheribbed
V-beltaroundtherotorpulleyassembly.
Note:InstallnewribbedV-belteachtimetheV-beltisinstalled.Failuretodo
socanresultinimpairedrotorfunction.
4.Installthebeltcovertothehousing.Installtheplasticscrewsecuringthebelt
covertotheLHframeplateassembly.Installthe3screwssecuringthebelt
covertothehousing.T orquethescrewsto1.7–2.3N•m(15–20in-lb).
