Toro 39901 - Chute Replacement

ChuteGearInstallation(continued)
g320303
Figure50
14.Installthe2screwssecuringthecontrollercovertothebatterycontainerskirt.
Torquethescrewsto1.1-1.7N•m(10-15in-lb).
15.Installthechutecontrolrod.
WARNING
Whenremovingorinstallingthebattery,donotallowthebattery
terminalstotouchanymetalpartsofthemachine.Donotallow
metaltoolstoshortbetweenthebatteryterminalsandmetalparts
ofthemachine.
16.Installthebatteryintothemachine.
ChuteReplacement
ChuteRemoval
1.Parkthemachineonalevelsurfaceandwaitforallmovingpartstostop.
WARNING
Whenremovingorinstallingthebattery,donotallowthebattery
terminalstotouchanymetalpartsofthemachine.Donotallow
metaltoolstoshortbetweenthebatteryterminalsandmetalparts
ofthemachine.
2.Liftthebatterycoverandremovethebatteryfromthemachine.
3.Removethechutegear.ChuteGearRemoval(page6–4)
4.Removethe4screwssecuringtherearchutetothehousing.
Chute:ServiceandRepairs
Page6–14
