Toro 39901 - Motor Replacement

MotorDriverInstallation(continued)
g320303
Figure68
3.Installthe2screwssecuringthecontrollercovertothebatterycontainerskirt.
Torquethescrewsto1.1-1.7N•m(10-15in-lb).
4.Installthechutecontrolrod.
WARNING
Whenremovingorinstallingthebattery,donotallowthebattery
terminalstotouchanymetalpartsofthemachine.Donotallow
metaltoolstoshortbetweenthebatteryterminalsandmetalparts
ofthemachine.
5.Installthebatteryintothemachine.
MotorReplacement
MotorRemoval
1.Parkthemachineonalevelsurfaceandwaitforallmovingpartstostop.
WARNING
Whenremovingorinstallingthebattery,donotallowthebattery
terminalstotouchanymetalpartsofthemachine.Donotallow
metaltoolstoshortbetweenthebatteryterminalsandmetalparts
ofthemachine.
2.Liftthebatterycoverandremovethebatteryfromthemachine.
3.Pullandremovethechutecontrolrodfromthemachine.
4.Removethemotordriverfromthemachine.MotorDriverRemoval(page8–4)
