Toro 39901 - Chute Gear Replacement

ChuteGearReplacement
ChuteGearRemoval
1.Parkthemachineonalevelsurfaceandwaitforallmovingpartstostop.
WARNING
Whenremovingorinstallingthebattery,donotallowthebattery
terminalstotouchanymetalpartsofthemachine.Donotallow
metaltoolstoshortbetweenthebatteryterminalsandmetalparts
ofthemachine.
2.Liftthebatterycoverandremovethebatteryfromthemachine.
3.Pullandremovethechutecontrolrodfromthemachine.
4.Removethe2screwssecuringthecontrollercovertothebatterycontainer
skirt.Removethecontrollercoverfromthebatterycontainer.
5.Removethe4screwssecuringthemotordrivertothebatterycontainerskirt.
g320303
Figure31
6.Liftthemotordriverfromthebatterycontainerskirtanddisconnectallthe
wireattachments.Removethemotordriver.
7.Removethe2screwssecuringthebatterycontainerskirttothebattery
container.
