RibbedV-BeltInstallation(continued)
g320499
Figure18
1.PlasticScrew2.Screws
WARNING
Whenremovingorinstallingthebattery,donotallowthebattery
terminalstotouchanymetalpartsofthemachine.Donotallow
metaltoolstoshortbetweenthebatteryterminalsandmetalparts
ofthemachine.
5.Installthebatteryintothemachine.
RotorReplacement
RotorRemoval
1.Parkthemachineonalevelsurfaceandwaitforallmovingpartstostop.
WARNING
Whenremovingorinstallingthebattery,donotallowthebattery
terminalstotouchanymetalpartsofthemachine.Donotallow
metaltoolstoshortbetweenthebatteryterminalsandmetalparts
ofthemachine.
2.Liftthebatterycoverandremovethebatteryfromthemachine.
3.RemovetheribbedV-belt.RibbedV-BeltReplacement(page5–4)
4.Removethe3screwssecuringtheLHframeplatetothehousingandLH
extension.
