Toro 39901 - Ribbed V-Belt Replacement

RibbedV-BeltReplacement
RibbedV-BeltRemoval
1.Parkthemachineonalevelsurfaceandwaitforallmovingpartstostop.
WARNING
Whenremovingorinstallingthebattery,donotallowthebattery
terminalstotouchanymetalpartsofthemachine.Donotallow
metaltoolstoshortbetweenthebatteryterminalsandmetalparts
ofthemachine.
2.Liftthebatterycoverandremovethebatteryfromthemachine.
3.RemovetheplasticscrewsecuringthebeltcovertotheLHframeplate
assembly.Removethe3screwssecuringthebeltcovertothehousing.
Removethebeltcoverfromthemachine.
g320499
Figure15
1.PlasticScrew2.Screws
4.RemovethescrewandBellevillewashersecuringtherotorpulleyassembly
totherotorshaft.
g323087
Figure16
DriveSystem:ServiceandRepairs
Page5–4
60VMAXe21PowerClear®SnowThrowerwith
Flex—ForcePowerSystem®ServiceManual
3438-775RevA
