Toro 39901 - Motor Driver Replacement

MotorDriverReplacement
MotorDriverRemoval
1.Parkthemachineonalevelsurfaceandwaitforallmovingpartstostop.
WARNING
Whenremovingorinstallingthebattery,donotallowthebattery
terminalstotouchanymetalpartsofthemachine.Donotallow
metaltoolstoshortbetweenthebatteryterminalsandmetalparts
ofthemachine.
2.Liftthebatterycoverandremovethebatteryfromthemachine.
3.Pullandremovethechutecontrolrodfromthemachine.
4.Removethe2screwssecuringthecontrollercovertothebattery.
5.Removethe4screwssecuringthemotordrivertothebatterycontainerskirt.
g320303
Figure67
6.Liftthemotordriverfromthebatterycontainerskirtanddisconnectallthe
wireattachments.Removethemotordriver.
MotorDriverInstallation
1.Connectallthewireattachmentstothemotordriver.
2.Installthe4screwssecuringthemotordrivertothebatterycontainerskirt.
Torquethescrewsto1.1-1.7N•m(10-15in-lb).
Motor:ServiceandRepairs
Page8–4
