ChuteGearInstallation(continued)
10.Installthe2screwssecuringthebatterycontainerskirttothebattery
container.T orquethescrewsto1.1-1.7N•m(10-15in-lb)
g320276
Figure48
11.Installthe3screwssecuringthebatterycontainerskirttothebattery
container.Torquethescrewsto1.1-1.7N•m(10-15in-lb).
g320289
Figure49
12.Connectallwiringtothemotordriver.
13.Installthe4screwssecuringthemotordrivertothebatterycontainerskirt.
Torquethescrewsto1.1-1.7N•m(10-15in-lb).
60VMAXe21PowerClear®SnowThrowerwith
Flex—ForcePowerSystem®ServiceManual
Page6–13
Chute:ServiceandRepairs
3438-775RevA
