ChuteGearInstallation(continued)
g320271
Figure46
8.Installtheshroudontotherearchute.Installthe3screwssecuringthe
shroudtotherearchute.T orquethescrewsto1.1-1.7N•m(10-15in-lb).
9.Installthebatterycontainertothebulkhead.Installthe4screwsand
washerssecuringthebatterycontainertothebulkhead.T orquethescrewsto
1.1-1.7N•m(10-15in-lb).
g320297
Figure47
Chute:ServiceandRepairs
Page6–12
60VMAXe21PowerClear®SnowThrowerwith
Flex—ForcePowerSystem®ServiceManual
3438-775RevA
