ChuteRemoval(continued)
g320296
Figure51
5.Liftandremovetherearchuteandchutefromthehousing.
g321113
Figure52
ChuteInstallation
1.Installthechuteandrearchuteontothehousing.
2.Installthe4screwssecuringtherearchutetothehousing.Torquethescrews
to1.7–2.3N•m(15–20in-lb).
60VMAXe21PowerClear®SnowThrowerwith
Flex—ForcePowerSystem®ServiceManual
Page6–15
Chute:ServiceandRepairs
3438-775RevA
