MotorInstallation(continued)
2.Installthe3screwssecuringthemotortotheLHframeplate.T orquethe
screwsto8.5–11.3N•m(75–100in-lb).
g320288
Figure81
3.Installtherotorpulleyassemblytotherotorshaft.InstalltheBellevillewasher
andnewscrewsecuringtherotorpulleyassemblytotherotorshaft.T orque
screwto10–12.4N•(90-110in-lb).
g323087
Figure82
4.ApplyLoctitetothemotorpulleythreads.
5.ThreadthenewribbedV-beltaroundthemotorpulleyandroutetheribbed
V-beltaroundtherotorpulleyassembly.
Note:InstallanewribbedV-belteachtimetheribbedV-beltisinstalled.
Failuretodosocanresultinimpairedrotorfunction.
6.Installthebeltcovertothehousing.Installtheplasticscrewsecuringthebelt
covertotheLHframeplateassembly.Installthe3screwssecuringthebelt
covertothehousing.T orquethescrewto1.7–2.3N•m(15–20in-lb).
