Toro 51487 - Charging the Battery Pack; Charging Instructions; Advancing the Line; Advancing the Line Manually

ChargingtheBatteryPack
Important:Forbestresults,yourbatterytoolshouldbe
chargedinalocationwherethetemperatureismorethan
41degreesF(5degreesC)butlessthan104degreesF(40
degreesC).Toreducetheriskofseriouspersonalinjury,
donotstoreoutsideorinvehicles.Chargingtimewillbe
increasedifnotchargedwithinthisrange.
1.Turnthebatteryupsidedownandlineupthebatteryterminal
withtheslotinthecharger(
Figure12andFigure13).
G017407
1
2
Figure12
1.LEDindicators2.Insertbatteryhere
G016223
1
2
3
Figure13
1.LEDindicators(levelof
charge)
3.Batteryterminal
2.Releasebutton
2.Slidethebatteryintothechargeruntilitclicksintoplace.
3.Toremovethebattery,pressdownonthereleasebutton
andslidethebatterybackwardsoutofthecharger.
4.RefertothetablebelowtointerprettheLEDindicatorson
thebatterycharger.
LEDCOLOR
Left
RightIndicates:
RedRedBatteryischarging
Red
Green
Fullycharged
Red
Orange
Batteryistoo
warm:Remove
forapproximately
30minutes
Red
Green
Nobatterypresent
Red(blinking)Red(blinking)Defectivebattery
AdvancingtheLine
Thetrimmerisequippedwithanauto-feedhead.Thelinewill
advance6mm(1/4inch)eachtimeyoustopandstartthe
trimmer.Whenthelinereachesthebladeinthedeector,itwill
becutoffatthatlength.
1.Withthetrimmerrunning,releasetheswitchtrigger.
2.Waittwoseconds,thenpresstheswitchtrigger.
3.Resumetrimming.
AdvancingtheLineManually
Disconnectthestringtrimmerfromthepowersupply,thenpush
theredbuttonatthebaseofthespoolretainerwhilepullingonthe
trimmerlinetomanuallyadvancetheline.
Figure14
1.Button
