AssemblingtheTrimmer
NoPartsRequired
Procedure
1.Removethetapeandthetubefromtheupperpole
(
Figure2).
Figure2
1.Tube3.Lowerpole
2.Tape
2.Slidetheupperpoleintothelowerpole,liningupthetabin
theupperpolewiththereceivingtabsinthelowerpole,and
secureitbytighteningthescrew.
Note:Thereisanaudibleclickwhentheupperpoleand
lowerpoleareintheproperposition.
Figure3
1.Upperpole
3.Shaftclamp
2.Screw
3.Cutthezip-tieandremoveitfromthetriggerhandle
(Figure4).
Figure4
1.Zip-tie
