Toro 51487 - Installing the Edge Guard; Edge Guard Installation; Adjusting the Handle Height and Base Orientation; Handle and Base Adjustment

5
InstallingtheEdgeGuard
Partsneededforthisprocedure:
1Wireedgeguard
Procedure
Inserttheendsofthewireedgeguardintotheholesinthetrimmer
housing,asshownin
Figure7.
G017621
1
Figure7
1.Wireedgeguard
6
AdjustingtheHandleHeight
andBaseOrientation
NoPartsRequired
Procedure
•Toadjusttheauxiliaryhandleheight,releasetheauxiliary
handlelatch,slidetheauxiliaryhandleupordowntothe
desiredheight,thensecuretheauxiliaryhandleinplaceby
closingtheauxiliarylatch(Figure8).
Figure8
1.Auxiliaryhandle2.Auxiliaryhandlelatch
•Toadjusttheorientationofthebase,pressdownonthe
rotatorbuttonlocatedatthebaseoftheshaft,thenmovethe
basetofacethedesireddirection(Figure9).
1
G015683
Figure9
1.Rotatorbutton
8
