Toro 58602 - Washer-M8; Lock Pin; Bolt-M8 X 20 MM; Parts Needed for this Procedure

g356257
Figure7
1.Bolt—M8x20mm(2)3.Locknut—M8(2)
2.Washer—M8(2)
6.Insertthedragstakethroughthebottomopening
inthelowertailmountandsecureitwiththe
lockpin.
g356254
Figure8
1.Lockpin2.Dragstake
7.Installthedragstakehandleassemblytothe
dragstake.
g356436
Figure9
2
AddingOiltotheEngine
Partsneededforthisprocedure:
1Engineoil
Procedure
Important:Iftheoillevelintheengineistoo
lowortoohighandyouruntheengine,youmay
damagetheengine.
1.Movethemachinetoalevelsurface.
2.Carefullypourabout3/4oftheenginecapacity
ofoilintotheoil-lltube.
3.Wait3minutesfortheoiltosettleintheengine.
4.Wipethedipstickcleanwithacleancloth.
g334792
Figure10
1.Dipstick3.Add
2.Full
5.Insertthedipstickintotheoil-lltube,then
removethedipstick.
6.Readtheoillevelonthedipstick(Figure10).
•Iftheoillevelonthedipstickistoolow,
carefullypourasmallamountofoilintothe
oil-lltube,wait3minutes,andrepeatsteps
4through6untiltheoillevelonthedipstick
iscorrect.
•Iftheoillevelonthedipstickistoohigh,
draintheexcessoiluntiltheoillevelonthe
dipstickiscorrect.
Important:Iftheoillevelintheengineistoo
lowortoohighandyouruntheengine,you
maydamagetheengine.
7.Installthedipstickintotheoil-lltubesecurely.
8.Recycletheusedoilproperly.
8
