Toro 58602 - Setup; Assembling the Tiller

Setup
LooseParts
Usethechartbelowtoverifythatallpartshavebeenshipped.
ProcedureDescription
Qty.
Use
Wheel2
Tineshield1
Bolt(M8x20mm)
4
Hairpincotter2
Lockpin1
Washer(M8)
4
Bolt(M8x45mm)
2
Locknut(M8)
6
Washer(12mm)
2
Bolt(M6x16mm)
4
Locknut(M6)
4
Dragstakehandleassembly1
Axle1
Leftoutertine
1
1
Rightoutertine1
Assemblethetiller.
2
Engineoil1Addoiltotheengine.
1
AssemblingtheTiller
Partsneededforthisprocedure:
2Wheel
1Tineshield
4
Bolt(M8x20mm)
2Hairpincotter
1Lockpin
4
Washer(M8)
2
Bolt(M8x45mm)
6
Locknut(M8)
2
Washer(12mm)
4
Bolt(M6x16mm)
4
Locknut(M6)
1Dragstakehandleassembly
1Axle
1
Leftoutertine
1Rightoutertine
Procedure
1.Installtheaxleandwheelstothelowertail
mount.
g356258
Figure3
1.Axle
4.Washer—12mm(2)
2.Lowertailmount
5.Hairpincotter(2)
3.Wheel(2)
6
