2.Installthetineshield.Aligntheslotsonboth
sidesoftheshieldandinsertthefasteners
beforetighteningthem.
Important:Ensurethatthedirtshieldis
betweentheengine-mountdeckandtine
shield.
g356256
Figure4
1.Bolt—M6(4)
4.Enginemountdeck
2.Tineshield5.Dirtshield
3.Locknut—M6(4)
3.Installthetinestothedesiredposition;referto
ChangingtheTillingWidth(page10).
4.Installtheupperhandleassemblyontothelower
loopmount.
Note:Installtheboltswiththeheadfacing
outward.
g356424
Figure5
1.Bolt—M8x20mm(2)3.Locknut—M8(2)
2.Washer—M8(2)
5.Rotatethehandletothedesiredpositionand
installtheupperfasteners.
Note:Usethefrontholeforthehighestposition;
usetherearholeforthelowestposition.Install
theboltswiththeheadfacingoutwardasshown
inFigure7.
g356255
Figure6
1.Highposition4.Upperbolt
2.Middleposition5.Lowerbolt
3.Lowposition6.Lowerloopmount
7
