Toro 58602 - Product Overview; Controls; Specifications; Figure 11

ProductOverview
g355853
Figure11
1.Drive-controllever7.Tineshield
2.Adjustablecable8.Hingedtailmount
3.Bumper9.Wheel
4.Drivebeltcover10.Handlebarheight
adjustment
5.Tines11.Handgrip
6.Tinewidthadjustment
12.Engineon/offswitch
Controls
Drive-ControlLever
Squeezethedrive-controllevertothehandgripto
engagethetines.Releaseittodisengagethetines.
EngineOn/OffSwitch
UsetheengineOn/Offswitchtoshuttheengineoff.
EnsurethattheswitchisintheONpositionbefore
startingtheengine.
Specications
Specicationsanddesignaresubjecttochange
withoutnotice.
Height
117.9cm(46.4inches)
Length
122.2cm(48.1inches)
Width
55.9cm(22.0inches)
Weight
46.7kg(103lb)
Tillingwidth
28to53cm(11to21inches)
Tillingdepth
Upto28cm(11inches)
Toensureoptimumperformanceandcontinuedsafety
certicationofthemachine,useonlygenuineT oro
replacementpartsandaccessories.Replacement
partsandaccessoriesmadebyothermanufacturers
couldbedangerous,andsuchusecouldvoidthe
productwarranty.
