7.Installthecontrolrodtotheblade-controlhandle
andcontrolarmasshowninFigure8andFigure
9.
g384286
Figure8
1.Controlrod
2.Hairpincotter
g384285
Figure9
1.Hairpincotter
3
InstallingtheWheels
Partsneededforthisprocedure:
2Frontwheel
2Rearwheel
1Frontaxle
1Rearaxle
2Hairpincotter
4Axlespacer
1Wheel-positionspacer
2
Locknut(M10)
Procedure
1.Installthefrontwheelsontothefrontaxle.
Note:Thefrontwheelsaresmallerthanthe
rearwheels.
g384419
Figure10
1.Frontaxle
4.Frontwheel(2)
2.Hairpincotter(2)
5.Wheel-positionspacer
3.Axlespacer(2)
