InstallingtheDischarge
Chute
Partsneededforthisprocedure:
1Dischargechute
4
Screw
Procedure
Installthedischargechutetothemowerdeckas
shown.
g342810
Figure4
1.Screw(4)
2.Dischargechute
3
AddingOiltotheEngine
Partsneededforthisprocedure:
1Engineoil
Procedure
Important:Iftheoillevelintheengineistoo
lowortoohighandyouruntheengine,youmay
damagetheengine.
1.Movethemachinetoalevelsurface.
2.Carefullypourabout3/4oftheenginecapacity
ofoilintotheoil-lltube.
3.Wait3minutesfortheoiltosettleintheengine.
4.Wipethedipstickcleanwithacleancloth.
g334792
Figure5
1.Dipstick3.Add
2.Full
5.Insertthedipstickintotheoil-lltube,then
removethedipstick.
6.Readtheoillevelonthedipstick(Figure5).
•Iftheoillevelonthedipstickistoolow,
carefullypourasmallamountofoilintothe
oil-lltube,wait3minutes,andrepeatsteps
4through6untiltheoillevelonthedipstick
iscorrect.
•Iftheoillevelonthedipstickistoohigh,
draintheexcessoiluntiltheoillevelonthe
dipstickiscorrect.
Important:Iftheoillevelintheengineistoo
lowortoohighandyouruntheengine,you
maydamagetheengine.
7.Installthedipstickintotheoil-lltubesecurely.
8.Recycletheusedoilproperly.
