DriveSystem
Maintenance
RemovingandInstalling
theWheels
ServiceInterval:Every25hours—Lubricatethe
jackshaftassembly.
Removeandinstallthewheelsasshown.
g337013
Figure18
1.Axlenut
3.Spacer
2.Wheel4.Lockwasher
ReplacingtheDriveBelt
1.Removethe2fastenerssecuringtherearofthe
shieldtothemowerhousing.
g337959
Figure19
1.Rearfastener(2)
4.Mowerhead
2.Frontfastener(4)
5.Drivebelt
3.Shield
2.Removethe4fastenerssecuringthefrontofthe
shieldandmowerheadtothemowerhousing.
3.Raisethefrontofthemowerhousing,loosenthe
mountingboltonthedrivepulley,andremove
the“V”pulleyfromtheidlerbracket.
Important:Donotbendthebeltguides.
g337960
Figure20
1.Drivepulley3.Drivebelt
2.Beltguide
4.“V”pulley
4.Removethedrivebeltandinstallanewone.
5.Installthe“V”pulleytotheidlerbracket.
