Toro 58620 - Filling the Fuel Tank; Adjusting the Handle Height and Angle; Performing Daily Maintenance

FillingtheFuelTank
FillthefueltankasshowninFigure7.
g230458
Figure7
AdjustingtheHandle
HeightandAngle
1.Holdingthehandlewith1hand,loosenboth
handle-adjustmentknobsuntiltheratchetteeth
aredisengaged.Donotremovetheknobs.
2.Adjustthehandletothedesiredpositionand
aligntheratchetteeth.Ensurethatbothsides
arelevel.
3.Tightentheknobs.
g334885
Figure8
1.Handle-adjustmentknob2.Ratchetteeth
PerformingDaily
Maintenance
Beforestartingthemachineeachday,performthe
EachUse/DailyprocedureslistedinMaintenance
(page12).
AdjustingtheHeightofCut
Youcanadjusttheheightofcutfrom38to76mm
(1-1/2to3inches).Therecommendedcuttingheight
formostyardsis51mm(2inches).
1.Movethemachinetoalevelsurface,shutoffthe
engine,andwaitforallmovingpartstostop.
2.Disconnectthespark-plugwirefromthespark
plug.
3.UsetheL-handlewrenchprovidedwiththe
machinetoloosenthe2capscrews.
4.Adjustthemowerheadtothedesiredheight.
5.Tightenthecapscrews.
6.Connectthesparkplug.
g335100
Figure9
1.Height-of-cutpositions
4.Heightguide
2.Mowerhead
5.Capscrews
3.L-handlewrench
