Toro 70089 - Assembly; Loose Parts

12
Assembly
Loose Parts
Note: Use the chart below to verify all parts have been shipped.
DESCRIPTION QTY. USE
Seat
Wire Tie
Clamp
Seat Spacer (rubber)
Seat Spacer (metal)
Washer, 5/16” I.D.
Screw, 5/16”–18 x 1 1/2” (38 mm)
Locknut
1
1
1
2
2
2
2
2
Install Seat, page 13.
Front Wheel Assembly
Flat Washer
Hub Cap
Cotter Pin
2
2
2
2
Install Front Wheels, page 13
Steering Wheel
Roll Pin
Steering Shaft Cover
1
1
1
Install Steering Wheel Assembly, page 13
Key 2 Use in ignition and ”Key Choice” Switches
Capscrew
Wing Nut
2
2
Secure battery cables to battery, page 15.
Hose coupling 1
Connect garden hose to washout port during
maintenance.
Operator’s Manual 1 Read manual before operating rider.
Registration Card 1 Fill out and mail to Toro.
Hang Tag 1 Read for Warranty information.
