Operation
20
Lowering
Attachments
1. Start the tractor.
2. Push the lift lever DOWN to lower the
attachment (Fig. 17).
m–3315
1
2
Figure 17
1. Lift
lever–Up
2.
Lift lever–Down
Positioning
the Seat
The seat can move forward and backward. Position
the seat where you have the best control of the
machine and are most comfortable.
1. To adjust, move the lever sideways to unlock
seat (Fig. 18).
2. Slide the seat to the desired position and release
the lever to lock the seat into position.
IMPORTANT: Be sure that the seat is locked
in position before operating.
1
m–3320
Figure 18
1. Adjustment
lever
Headlights
and T
aillights
The headlights and taillights are turned on by turning
the ignition key to the LIGHTS position. They can
be turned on even if the engine is not running.
Remove the key when leaving the machine
unattended so that the headlights cannot be turned on
and discharge the battery.
m–3312
1
Figure 19
1. Lights
