Maintenance
37
Taillights
Bulb: GE 194
Removing the Bulb
1. Disengage the power take off (PTO), set the
parking brake, lower the attachment lift, and turn
the ignition key to “STOP” to stop the engine.
Remove the key.
2. Remove the two screws.
3. Pull the lens out far enough so that you can
remove the bulb socket.
4. Pull the bulb from the socket.
1
m–3321
2
3
4
Figure 50
1. Lens
2. Screws
3. Bulb
4. Socket
Installing the Bulb
Reverse the bulb removal procedure.
