Operating the Throttle
Y ou can move the throttle control between F AST and
S LOW positions ( Figure 23 ).
Always use the F AST position when engaging the PT O.
g008946
Figure 23
Operating the Choke
Use the choke to start a cold engine.
1. Pull up the choke knob to engage the choke
before using the key switch ( Figure 24 ).
2. Push down the choke knob to disengage the
choke after the engine has started ( Figure 24 ).
g008959
Figure 24
1. O N position 2. O FF position
25
