Toro 74292 - Machine Overview and Controls; Controls

106-9989
107-8076
1.Fast
2.Slow
3.Neutral4.Reverse
ProductOverview
Figure3
1.Motioncontrollever
5.Controls
2.Parkingbrakelever
6.Seatbelt
3.Height-of-cutlever
7.Rollbar
4.Fuelcap(bothsides)
Controls
Becomefamiliarwithallthecontrolsbeforeyoustartthe
engineandoperatethemachine(Figure3andFigure4).
Figure4
1.Gascap
4.Throttle
2.Choke5.Powertakeoff(PTO)
3.Ignitionswitch6.Hourmeter
11
