Toro 74292 - Mower Deck Leveling; Leveling the Mower at Three Positions

Electricalsystemwillnotperformpropersafety
shutoffwithjumperwireinstalled.
•Removejumperwirefromwireharness
connectorandplugconnectorintoseat
switchwhenadjustmentiscompleted.
•Neveroperatethisunitwithjumperinstalled
andseatswitchbypassed.
7.Afterbothpumpneutralsareset,shutoffthe
machine.
8.Removethejumperwirefromthewireharness
connectorandplugtheconnectorintotheseat
switch.
9.Installtheseatrodandlowertheseatintoposition.
10.Removethejackstands.
MowerDeck
Maintenance
LevelingtheMoweratThree
Positions
Important:Thereareonlythreemeasuring
positionsneededtolevelthemower.
SettingUptheMachine
1.Positionmoweronaatsurface.
2.DisengagethePTO,movethemotioncontrollevers
totheneutrallockedpositionandsettheparking
brake.
3.Stoptheengine,removethekey,andwaitforall
movingpartstostopbeforeleavingtheoperating
position.
4.Checktirepressureofallfourtires.Ifneeded,adjust
to13psi(90kPa)
5.Lowerthemowertothe3inch(76mm)height-of-cut
position.
6.Inspectthefourchains.Thechainsneedtohave
tension.
Note:Adjusttherearchainstothetopoftheslot,
wheretheyareattachedtothemower.
•Ifonerearchainisloose,lower(loosen)thefront
supportarmonthesameside.RefertoAdjusting
theFront-to-RearMowerPitch.
•Ifonefrontchainisloose,raise(tighten)the
frontsupportarmforthatchain.Referto
AdjustingtheFront-to-RearMowerPitch.
LevelingtheMowerSide-to-Side
1.Positiontherightbladeside-to-side(Figure58).
43
